2KW~8.8KW Gasoline Portable Generator

Victory exports a lot of compact gasoline generators ranging in capacity from 0.6 ~ 7.0 kVA to Middle East, South-Central Asia,  North America, Europe, Africa, and other countries around the world every year. These gasoline generators are widely used for a diverse range of needs, such as an emergency power source in the event of a power failure, outdoor construction work, outdoor leisure activities and for disasters and other emergencies. Since the company was found in 1999, we always do the best to improve the quality in order to meet the requirements of various customers. Therefore, Victory Honda or LT series engines emerged as required, which have high reliability, high quality, low emissions, and compact design. Honda or LT gasoline engine series of generators that incorporated a super light weight and compact constraction offering low fuel consumption and low noise. Victory Honda or LT engine adopted the design of overhead valve (OHV) mechanism and inclined cylinder, which comes from Honda company, and it's very popular in the world.

Features:

1. OHV design permits low fuel consumption and noise

2. Classical combustion-chamber shape and excellent suction exhaust effect which to improve combustion efficiency

3. Auto decompressing makes starting easy

4. Oil alert automatically shut off the engine

5. Reliable transistorized magneto-ignition system

6. Speedy start, smooth operation and low vibration

7. With the recoil starter which is easy started by a woman

8. With transistor magnet ignition device to ensure the stable perfomance of ignition & low fuel consumption


Technology

Frequency 50Hz, 3000RPM, Single-phase voltage 220V, 230V, 240V, etc.

Three-phase voltage 380V/220V, 400V/230V, 415V/240V, etc.

Frequency 60Hz, 3600RPM, Single-phase voltage 120V, 127V, 277V, etc.

Three-phase voltage 208V/120V, 220V/127V, 480V/277V, etc.

Power Factor: 1.0

Protection Standard: IP21-IP23

Model of Connection: 1 phase 2 lines, 3 phase 4 lines

Insulation Grade: H

Power Range: 0.6KW-7.0KW

Starting System: Recoil or Electric

Govern System: Centrifugal Mechanical

Air cleaner: Dual element

Rotor & Stator: 100% Copper wire

Fuel Efficient & High Output Operation: OHV design for increased efficiency and optimal power transfer

Exceotionally Quiet

1. Large capacity, multi-chamber exhaust system

2. Reduced mechanical noise due to light weight, noise-reducing materials

Fuel Tank: 8~10 hours continuous running under full load.


Applications

Refrigerator or Freezer

Microwave Oven

Furnace Fan, gas or fuel oil

Sump Pump

TV / DVD

Hair Dryer

Coffee Maker

Computer

Garage Door Opener

Incandescent Lights


2KW~8KW 50Hz Gasoline Portable Generator

GeneratorModel:VT2500CLVT3000CLVT3800CLVT5000CLVT6500CLVT7500CLVT9000CLVT10000CL
Frequency (Hz)5050505050505050
Rated.AC output (KVA)2.0 2.33.0 4.0 5.0 6.0 6.5 7.5
Max.AC output (KVA)2.32.53.34.55.56.5 7.0 8.0
Voltage110V-240V110V-240V110V-240V110V-240V110V-240V110V-240V110V-240V110V-240V
PhaseSingle phaseSingle phaseSingle phaseSingle phaseSingle phaseSingle phaseSingle phaseSingle phase
D.C. output/V-A12/8.312/8.312/8.312/8.312/8.312/8.312/8.312/8.3
Power factor(cosΦ)1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
Alternator typeSelf-excited,2-pole,single phase Self-excited,2-pole,single phase Self-excited,2-pole,single phase Self-excited,2-pole,single phase Self-excited,2-pole,single phase Self-excited,2-pole,single phase Self-excited,2-pole,single phase Self-excited,2-pole,single phase
Material of winding100% Copper Wire100% Copper Wire100% Copper Wire100% Copper Wire100% Copper Wire100% Copper Wire100% Copper Wire100% Copper Wire
Noice level at 7 M (dBA)67 68 69 75 75 75 76 76
EngineEngine ModelHonda GX160 or LT210Honda GX160 or LT210Honda or LT225Honda or LT420Honda or LT420Honda or LT420Honda or LT460Honda or LT460
Type1-cylinder, 4 stroke, air-cooled, OHV1-cylinder, 4 stroke, air-cooled, OHV1-cylinder, 4 stroke, air-cooled, OHV1-cylinder, 4 stroke, air-cooled, OHV1-cylinder, 4 stroke, air-cooled, OHV1-cylinder, 4 stroke, air-cooled, OHV1-cylinder, 4 stroke, air-cooled, OHV1-cylinder, 4 stroke, air-cooled, OHV
Bore×stroke(mm)70*5470*5470*5890*6690*6690*6692*6992*69
Speed (rpm)30003000300030003000300030003000
Displacement (cc)208208223420420420458458
Compression ratio8.5:18.5:18.0:18.0:18.0:18.0:18.0:18.0:1
Max. Output7HP(5.1KW)7HP(5.1KW)7.5HP (5.5KW)16HP (11.8KW)16HP (11.8KW)16HP (11.8KW)18HP (13.2KW)18HP (13.2KW)
Rated Output5.5HP(4.0KW)5.5HP(4.0KW)6.0HP(4.4KW)11HP(8.1KW)11HP(8.1KW)11HP(8.1KW)12.3HP(9.0KW)12.3HP(9.0KW)
Max. Torque10.8N.m13.2N/m19N.m26.5N.m26.5N.m28N.m28N.m28N.m
Ignition SystemT.C.IT.C.IT.C.IT.C.IT.C.IT.C.IT.C.IT.C.I
Gasoline Consumption ≤630g/kw/h≤610g/kw/h≤580g/kw/h≤580g/kw/h≤520g/kw/h≤460g/kw/h≤460g/kw/h≤460g/kw/h
Fuel Tank Capacity1515152525252525
Lubracation SystemPressure splashedPressure splashedPressure splashedPressure splashedPressure splashedPressure splashedPressure splashedPressure splashed
Lube oil capacity0.60.60.61.11.11.11.11.1
Starting systemRecoil/ElectricRecoil/ElectricRecoil/ElectricRecoil/ElectricRecoil/ElectricRecoil/ElectricRecoil/ElectricRecoil/Electric
DimensionsSize(LxWxH)590*433*483mm590*433*483mm590*433*483mm685*512*550mm685*512*550mm685*512*550mm685*512*550mm685*512*550mm
Net weight39kg39kg48kg80kg85kg87kg90kg94kg
20ft Container180PCS180PCS180PCS180PCS180PCS180PCS180PCS180PCS
40ft Container380PCS380PCS380PCS380PCS380PCS380PCS380PCS380PCS
Optional  FeaturesHandle & WheelsYesYesYesYesYesYesYesYes
Three phase voltageYesYesYesYesYesYesYesYes




2.3KW~8.8KW 60Hz Gasoline Portable Generator

GeneratorModel:VT2500CLVT3000CLVT3800CLVT5000CLVT6500CLVT7500CLVT9000CLVT10000CL
Frequency (Hz)6060606060606060
Rated.AC output (KVA)2.3 2.5 3.3 4.5 5.5 6.5 7.0 8.0
Max.AC output (KVA)2.52.83.85677.7 8.8
Voltage110V-240V110V-240V110V-240V110V-240V110V-240V110V-240V110V-240V110V-240V
PhaseSingle phaseSingle phaseSingle phaseSingle phaseSingle phaseSingle phaseSingle phaseSingle phase
D.C. output/V-A12/8.312/8.312/8.312/8.312/8.312/8.312/8.312/8.3
Power factor(cosΦ)1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
Alternator typeSelf-excited,2-pole,single phase Self-excited,2-pole,single phase Self-excited,2-pole,single phase Self-excited,2-pole,single phase Self-excited,2-pole,single phase Self-excited,2-pole,single phase Self-excited,2-pole,single phase Self-excited,2-pole,single phase
Material of winding100% Copper Wire100% Copper Wire100% Copper Wire100% Copper Wire100% Copper Wire100% Copper Wire100% Copper Wire100% Copper Wire
Noice level at 7 M (dBA)78 78 80 84 84 88 76 76
EngineEngine ModelHonda GX160 or LT210Honda GX160 or LT210Honda or LT225Honda or LT420Honda or LT420Honda or LT420Honda or LT460Honda or LT460
Type1-cylinder, 4 stroke, air-cooled, OHV1-cylinder, 4 stroke, air-cooled, OHV1-cylinder, 4 stroke, air-cooled, OHV1-cylinder, 4 stroke, air-cooled, OHV1-cylinder, 4 stroke, air-cooled, OHV1-cylinder, 4 stroke, air-cooled, OHV1-cylinder, 4 stroke, air-cooled, OHV1-cylinder, 4 stroke, air-cooled, OHV
Bore×stroke(mm)70*5470*5470*5890*6690*6690*6692*6992*69
Speed (rpm)36003600360036003600360036003600
Displacement (cc)208208223420420420458458
Compression ratio8.5:18.5:18.0:18.0:18.0:18.0:18.0:18.0:1
Max. Output7HP(5.1KW)7HP(5.1KW)7.5HP (5.5KW)16HP (11.8KW)16HP (11.8KW)16HP (11.8KW)18HP (13.2KW)18HP (13.2KW)
Rated Output5.5HP(4.0KW)5.5HP(4.0KW)6.0HP(4.4KW)11HP(8.1KW)11HP(8.1KW)11HP(8.1KW)12.3HP(9.0KW)12.3HP(9.0KW)
Max. Torque10.8N.m13.2N/m19N.m26.5N.m26.5N.m28N.m28N.m28N.m
Ignition SystemT.C.IT.C.IT.C.IT.C.IT.C.IT.C.IT.C.IT.C.I
Gasoline Consumption ≤630g/kw/h≤610g/kw/h≤580g/kw/h≤580g/kw/h≤520g/kw/h≤460g/kw/h≤500g/kw/h≤490g/kw/h
Fuel Tank Capacity1515152525252525
Lubracation SystemPressure splashedPressure splashedPressure splashedPressure splashedPressure splashedPressure splashedPressure splashedPressure splashed
Lube oil capacity0.60.60.61.11.11.11.11.1
Starting systemRecoil/ElectricRecoil/ElectricRecoil/ElectricRecoil/ElectricRecoil/ElectricRecoil/ElectricRecoil/ElectricRecoil/Electric
DimensionsSize(LxWxH)590*433*483mm590*433*483mm590*433*483mm685*512*550mm685*512*550mm685*512*550mm685*512*550mm685*512*550mm
Net weight39kg39kg48kg80kg85kg87kg90kg94kg
20ft Container180PCS180PCS180PCS180PCS180PCS180PCS180PCS180PCS
40ft Container380PCS380PCS380PCS380PCS380PCS380PCS380PCS380PCS
Optional  FeaturesHandle & WheelsYesYesYesYesYesYesYesYes
Three phase voltageYesYesYesYesYesYesYesYes
