Cummins Inc., a global power leader, is a corporation of complementary business units that design, manufacture, distribute and service engines and related technologies, including fuel systems, controls, air handling, filtration, emission solutions and electrical power generation systems. Headquartered in Columbus, Indiana (USA), Cummins serves customers in approximately 190 countries and territories through a network of more than 500 Company-owned and independent distributor locations and approximately 5, 200 dealer locations.
Cummins marine auxiliary diesel generators are composed of 4BT, 6BT, 6CT, NT, KT marine engines produced by China Cummins Joint Venture Company, and Stamford or Marathon series brushless 3 phases generator. The gensets possess closed cooling water system and protection features for high water oil temperature, low oil pressure and over speed. The rotor of generator is designed of non-salient pole type and provided dampling windings and brushless excitation system.
Victory Cummins series diesel gensets offered by Victory Power Generation are manufactured strictly accord to the ISO9001:2000 international quality management system. Our company has commanded the design of diesel gensets well with the overseas companies' great support and the years' experience. Besides the design of industry workshop, our company also has good experience with the design for the monitors in intellectualized building, including connection, remote device, engine room without on duty, soundproof design and installation. Up till now, there are thousands gensets with control monitor provided by Victory Power Generation, which proves the high preponderant situation of Victory Power Generation.
Frequency 50HZ, 1500RPM, Rating voltage 380V/220V, 400V/230V, 415V/240V
Frequency 60HZ, 1800RPM, Rating voltage 208V/120V, 220V/127V, 480V/277V
Power Factor 0.8(lagging)
Protection Standard: IP23
Model of Connection: 3 phases 4 wires
Insulation Grade: H
stable voltage ≤±2.5%
voltage-form distortion rate≤5%
With brushless excitation
1. Brand new famous USA Brand Cummins Marine type water-cooled diesel engine
2. Marine type synchronous A.C. Alternator Self with Self-excitation or PMG Systems, with AVR delivering non fluctuating power
3. Cooling system: heater exchanger and sea water pump
4. Good quality MCCB breaker mounted
5. Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable
6. 24V DC electric start system
7. Industrial primary silencer with flexible connection elbows
8. Standard tool kits
9. Test report, Set of drawings and Operation&Maintenance English manuals
1. Free maintenance lead-acid starting battery and its cables
2. Fuel tank for at least 8~10 hours continuous running under full load, with fuel gauge integrated on base frame
3. Mounted intelligent famous Brand Smartgen HGM6120 control panel with Auto Starting System
Protection Function: High temperature, Over speed, Low Speed, Low Oil Pressure, Over voltage, Over current, Undervoltage.
3. Extemal recessed emergency stop button for extra safety.
4. Weatherproof and soundproof enclosure high grade steel protected by powder coat painting
5. Radiator with engine driven fan mounted on skid for those Emergency Generators
6- ATS: Automatic transfer switch bewteen mains power and generating power
38KVA~1100KVA 50Hz Cummins Marine Generator Set
|Genset Model||Frequency (Hz)||Prime Power||Stanby Power||Current (A)||Voltage (V)||Engine Model||Engine Power(KW)||Rated Speed (rpm)||Cylinder|
44KVA~1031KVA 60Hz Cummins Marine Generator Set
|Genset Model||Frequency (Hz)||Prime Power||Stanby Power||Current (A)||Voltage (V)||Engine Model||Engine Power (KW)||Rated Speed (rpm)||Cylinder|
