20KVA~1718KVA Cummins Diesel Generator Set

Cummins Inc., a global power leader, is a corporation of complementary business units that design, manufacture, distribute and service engines and related technologies, including fuel systems, controls, air handling, filtration, emission solutions and electrical power generation systems. Headquartered in Columbus, Indiana (USA), Cummins serves customers in approximately 190 countries and territories through a network of more than 500 Company-owned and independent distributor locations and approximately 5, 200 dealer locations.


Victory Cummins series diesel gensets offered by Victory Power Generation are manufactured strictly accord to the ISO9001:2000 international quality management system. Our company has commanded the design of diesel gensets well with the overseas companies' great support and the years' experience. Besides the design of industry workshop, our company also has good experience with the design for the monitors in intellectualized building, including connection, remote device, engine room without on duty, soundproof design and installation. Up till now, there are thousands gensets with control monitor provided by Victory Power Generation, which proves the high preponderant situation of Victory Power Generation.


1. Dongfeng Cummins 4B, 6B, 6C, 6L series 4-stroke diesel engine

2. Chongqing Cummins N, M, K19, K38, K50 series, 4-stroke diesel engine, Xi'an Cummins Q series

3. Fuel system: direct or electronic injection

4. Starting system: 24V direct current strating-up

5. Cooling system: water cooling system with a fan

6. Auto / manual starting up and shutting down control system

7. All kinds of monitor meters and switch selecting

8. High water temperature, low oil pressure, overspeed alarm function

9. Low cost, high efficiency, compact structure, environment friendly. 10. Excellent transient response. 11. Environment condition: Attitude ≤1000m, Ambient medium (air) temperature ≤40℃, and good ventilation.


Genset Speicifications:

Frequency 50HZ, 1500RPM, Rating voltage 380V/220V, 400V/230V, 415V/240V

Frequency 60HZ, 1800RPM, Rating voltage 208V/120V, 220V/127V, 480V/277V

Power Factor 0.8 (lagging)

Protection Standard: IP23

Model of Connection: 3 phase 4 lines

Insulation Grade: H

Frequency Drop(%): ≤ 0.5

Transient state frequency deviation(%):(advertised power ) +10~-7

Frequency Recovery Time(S): ≤ 3

Voltage Recovery Time(S): ≤4

Waveform Distortion(%): ≤5

Voltage Regulation: +_1.0%


Features:

High fuel efficiency: fewer fuel consumption at leading level than other competitive products.

The turbocharger with waste gated design: optimizes operation across the torque curve resulting in excellent low-end torque.

Compacted yet durable and dependable engine: Cummins engines contain up to 40% fewer parts than competitive engines in its class. This results in a better power-to-weight ration, a less chance of failure and lower repair cost.

Advanced design and manufacturing: make the engine delivers superior performance and lower cost than competitive engines.

Excellent cold start performance: optional assistant cold starter with improved 6.6KW starter and intake air heater.

Excellent performance and advantage: adopt advanced design to achieve higher horsepower and lower weight.

Engine

Heavy load, durable 4-stroke water-cooled engine, excellent transient response. 4 valves each cylinder, stainless crankshaft, bolt, and cast iron steel and replaceable humid cylinder liner.

Cooling system 40℃: Standard radiator, with a fan.

Starting system: 24V DC starting motor, 30A battery charger

Supply starting current 625A-1800A at 0℃

Filtering system

Dry element air filter is fixed with operation indicator. Spin-on replaceable paper element full-flow filter; Spin-on replaceable paper element diesel filter.

Fuel cut off by 24V DC electromagnetic valve, double-layer spin-on paper element fuel filter, and unique PT oil supply electronic governed system, gen-set equipped with double flexible fuel union                     pipe.


20KVA~1650KVA 50HZ Cummins Diesel Generator Set
ModelFrequency HZPrime PowerStandby PowerEngine ModelFull-Load Diesel
Consumption
(L/H)
Engine Displace-ment
 (L)
Cylinders and arrangementBore×Stroke
 (mm)
Compression RatioGovernor TypeInspirationDimension
L*W*H
Weight
(KG)
KWKVAKWKVA(mm)
V18C50162018234B3.9-G253.94L102×12016.5:1electronic governingNatural1750*970*1500850
V24C50212624306
V36C50324036454BT3.9-G293.94L102×12016.5:1electronic governingTurbocharged1750*970*1500950
V45C50405045564BTA3.9-G2133.94L102×12016.5:1electronic governingTurbocharged Intercooled1750*970*15001070
V53C50486053664BTA3.9-G11153.94L102×12017.3:1electronic governingTurbocharged1850*970*15001100
V65C505873658217.6
V75C50688575946BT5.9-G2215.96L102×12017.3:1electronic governingTurbocharged2160*1030*15501120
V92C50801009211522.3
V110C501001251101386BTA5.9-G2255.96L102×12017.3:1electronic governingTurbocharged Intercooled2160*1030*15501235
V120C501081351201506BTAA5.9-G2305.96L102×12017.3:1electronic governingTurbocharged Intercooled2320*1030*15501400
V132C501201501321656BTAA5.9-G12345.96L102×12017.3:1electronic governingTurbocharged Intercooled2320*1030*15501500
V140C501281601401756CTA8.3-G2388.36L114×13516.5:1electronic governingTurbocharged Intercooled2440*980*17101900
V160C5014418016020038
V180C501602001802256CTAA8.3-G2428.36L114×13516.8:1electronic governingTurbocharged Intercooled2520*980*17602300
V200C501802252002506LTAA8.9-G250146L114×14515:1electronic governingTurbocharged2570*1140*16802500
V220C502002502202756LTAA8.9-G355146L114×14515:1electronic governingTurbocharged2570*1140*16802500
V250C50220275250313NTA855-G1A62146L140×15214:1electronic governingTurbocharged Intercooled3050*1110*17652700
V280C50250313280350NTA855-G1B68146L140×15214:1electronic governingTurbocharged Intercooled3050*1110*17652700
V290C50260325290363QSM11-G26910.86L125x14716.3:1electronic governingTurbocharged Intercooled3050*1110*17653000
V310C50280350310388NTA855-G2A76146L140×15214:1electronic governingTurbocharged Intercooled3050*1110*17653000
V310C50280350310388NTA855-G476146L140×15214:1electronic governingTurbocharged Intercooled3050*1110*17653100
V330C50300375330413NTAA855-G783146L140×15214:1electronic governingTurbocharged Intercooled3200*1110*18053100
V350C50320400350438QSNT-G382146L140×15216.3:1electronic governingTurbocharged Intercooled3170*1380*18403300
V360C50330413360450NTAA855-G7A83146L140×15214:1electronic governingTurbocharged Intercooled3200*1110*18053300
V330C50300375330413KTA19-G283196L159×15913.9:1electronic governingTurbocharged Intercooled3370*1530*21004000
V400C50360450400500QSZ13-G271136L130x16317:1electronic governingTurbocharged Intercooled3450*1300*20004000
V400C50360450400500KTA19-G397196L159×15913.9:1electronic governingTurbocharged Intercooled3370*1530*21004000
V450C50400500450563QSZ13-G3101136L130x16317:1electronic governingTurbocharged Intercooled3170*1380*18404300
V450C50400500450563KTA19-G3A/ KTA19-G4107196L159×15913.9:1electronic governingTurbocharged Intercooled3370*1530*21004300
V505C50420525505631KTAA19-G5113196L159×15913.9:1electronic governingTurbocharged Intercooled3370*1530*21004600
V520C50460575520650KTAA19-G6127196L159×15913.9:1electronic governingTurbocharged Intercooled3700*1700*22004600
V550C50500625550688KTAA19-G6A130196L159×15913.9:1electronic governingTurbocharged Intercooled3700*1700*22004600
V570C50520650570713QSKTAA19-G4142196L159×15913.9:1electronic governingTurbocharged Intercooled3700*1700*22004600
V640C50580725640800KT38-G1403812V159×15915.5:1electronic governingTurbocharged4400*1750*21806950
V660C50600750660825KTA38-G21753812V159×15915.5:1electronic governingTurbocharged Intercooled4400*1750*21807050
V710C50640800710888KTA38-G2B1853812V159x15914.5:1electronic governingTurbocharged Intercooled4400*1750*21807200
V800C507289108001000KTA38-G2A1913812V159×15914.5:1electronic governingTurbocharged Intercooled4400*1750*21807200
V880C5080010008801100KTA38-G52093812V159×15913.9:1electronic governingTurbocharged Intercooled4380*2080*22007900
V1000C50900112510001250KTA38-G92223812V159×15913.9:1electronic governingTurbocharged Intercooled4380*2080*22008500
V1120C501020127511201400KTA50-G32615016V159×15913.9:1electronic governingTurbocharged Intercooled5000*2080*22828500
V1320C501200150013201650KTA50-GS83095016V159×15913.9:1electronic governingTurbocharged Intercooled5250*2110*251011000



20KVA~1718KVA 60HZ Cummins Diesel Generator Set
ModelFrequency HZPrime PowerStandby PowerEngine ModelFull-Load Diesel
Consumption
(L/H)
Engine Displace-ment
(L)
Cylinders and arrangementBore×Stroke
(mm)
Compression RatioGovernor TypeInspirationDimension
L*W*H
Weight (KG)
KWKVAKWKVA(mm)
V18C60162018234B3.9-G253.94L102×12016.5:1electronic governingNatural1750*970*1500850
V26C60243026337.2
V45C60405045564BT3.9-G2123.94L102×12016.5:1electronic governingTurbocharged1750*970*1500950
V55C60506355694BTA3.9-G2163.94L102×12016.5:1electronic governingTurbocharged Intercooled1750*970*15001070
V53C60486053664BTA3.9-G11153.94L102×12017.3:1electronic governingTurbocharged1850*970*15001100
V75C606885759420.1
V92C6080100921156BT5.9-G222.35.96L102×12017.3:1electronic governingTurbocharged2160*1030*15501120
V100C609011310012528.5
V110C601001251101386BTA5.9-G2295.96L102×12017.3:1electronic governingTurbocharged Intercooled2160*1030*15501235
V132C601201501321656BTAA5.9-G2365.96L102×12017.3:1electronic governingTurbocharged Intercooled2220*1030*15501400
V140C601281601401756BTAA5.9-G12385.96L102×12017.3:1electronic governingTurbocharged Intercooled2220*1030*15501500
V160C601441801602006CTA8.3-G2388.36L114×13516.5:1electronic governingTurbocharged Intercooled2440*980*17101900
V176C6016020017622044
V200C601802252002506CTAA8.3-G2488.36L114×13516.8:1electronic governingTurbocharged Intercooled2520*980*17602300
V220C602002502202756LTAA8.9-G255146L114×14515:1electronic governingTurbocharged2570*1140*16802500
V240C602202752403006LTAA8.9-G360146L114×14515:1electronic governingTurbocharged2570*1140*16802500
V275C60250313275343NTA855-G169146L140×15214:1electronic governingTurbocharged Intercooled3050*1110*17652700
V310C60280350310388NTA855-G1B77146L140×15214:1electronic governingTurbocharged Intercooled3050*1110*17652700
V330C60300375330413QSM11-G27710.86L125x14716.3:1electronic governingTurbocharged Intercooled3050*1110*17653000
V350C60320400350438NTA855-G383146L140×15214:1electronic governingTurbocharged Intercooled3050*1110*17653050
V400C60360450400500KTA19-G297196L159×15913.9:1electronic governingTurbocharged Intercooled3370*1530*21004000
V400C60360450400500QSZ13-G271136L130x16317:1electronic governingTurbocharged Intercooled3170*1380*18404000
V462C60420525462578KTA19-G3107196L159×15913.9:1electronic governingTurbocharged Intercooled3370*1530*21004000
V450C60400500450563QSZ13-G3101136L130x16317:1electronic governingTurbocharged Intercooled3170*1380*18404300
V500C60460575500625KTA19-G3A/ KTA19-G4118196L159×15913.9:1electronic governingTurbocharged Intercooled3370*1530*21004300
V560C60500625560700KTAA19-G5135196L159×15913.9:1electronic governingTurbocharged Intercooled3370*1530*21004600
V600C60560700600750KTAA19-G6A150196L159×15913.9:1electronic governingTurbocharged Intercooled3700*1700*22004600
V680C60620775680850KT38-G1673812V159×15915.5:1electronic governingTurbocharged4400*1750*21806950
V800C607289108001000KTA38-G21943812V159×15915.5:1electronic governingTurbocharged Intercooled4400*1750*21807050
V928C6083510449281160KTA38-G2A2003812V159×15914.5:1electronic governingTurbocharged Intercooled4400*1750*21807200
V1000C60910113810001250KTA38-G42303812V159×15913.9:1electronic governingTurbocharged Intercooled4380*2080*22007900
V1100C601000125011001375KTA38-G92403812V159×15913.9:1electronic governingTurbocharged Intercooled4380*2080*22008500
V1250C601135141812501610KTA50-G32915016V159×15913.9:1electronic governingTurbocharged Intercooled5000*2080*22828500
V1375C601200150013751718KTA50-G93305016V159x15913.9:1electronic governingTurbocharged Intercooled5250*2110*251013000
